Burner ratings
Max burner power : Yes
Power back left : 12,000 BTU
Power back right : 12,000 BTU
Power front centre : 20,000 BTU
Power front left : 12,000 BTU
Power front right : 12,000 BTU
Total cooktop power : 68,000 BTU
Controls
Metal dials : true
Gas requirements
Fitting and pipe : ½ NPT, min. ⅝" ∅ flex line
Supply Pressure (LPG) : 11" to 14" W.C
Performance
Sealed Dual Flow Burners™ : 5
Sealed cooking surface : true
Simmer on all burners : 140°F
Power requirements
Amperage : 15A
Supply frequency : 60Hz
Supply voltage : 120V
Product dimensions
Depth : 21"
Height : 5 1/2"
Width : 36"
Recommended Back Guards Ventilation
Downdraft : HD36
Minimum CFM : 600 BTU
Pro hood : HCB36-12 N / HCB36-6 N
Traditional hood : ES36
Safety
ADA compliant : true
Warranty
Parts and labor : 2 years
